Specialty Parts


In addition to our on-line Shopping Website, the following speciality parts are available. Email or call us at the contact information below if you are interested in a speciality part.


Hammond Parts


Part Number Description Amount
ST47 KIT 1147 ADAPTOR FOR 11 PIN SERIES XB-2/XB-5 261.00
6122 KIT 122 ADAPTER KIT A100/B3/C3/L100/L200 - NO CABLE 282.00
1122 KIT 122 KIT TO 11 PIN SERIES XB-2/XB-5 288.90
6147 KIT 147 ADAPTOR KIT A100/B3/C3/L100/L200 - NO CABLE 273.00
011 035752 8FT, 16-2, SPECIAL B3, KEYED ENDS 22.00
025 035671 A KEY, WHITE 15.00
025 035672 B KEY, WHITE 15.00
TP 2B B SERIES PRECUSSION KIT 289.00
SSP 1B B SERIES SOLID STATE PREAMP KIT 160.05
025 035666 C KEY, WHITE 15.00
025 035667 D KEY, WHITE 15.00
025 035668 E KEY, WHITE 15.00
025 035669 F KEY, WHITE 15.00
042 002429 FELT COVER, GENERATOR 6.00
025 035670 G KEY, WHITE 15.00
025 023309 LEFT CHEEK BLOCK PLASTIC 22.18
032 047642 LOCK KEY (MOST RECENT) 9.25
032 002849 LOCK KEY (OLD) 10.82
032 016268 LOCK KEY LATE (17-14) 12.00
032 047641 LOCK, CONSOLE B3 (MOST RECENT) 13.10
015 025581-4 OIL, HAMMOND B3 GENERATOR (LARGE 4OZ) 12.00
012 001800 PEDAL ACTUATOR, MUST TRADE IN OLD ONE 35.00
025 036295 SHARP KEY, BLACK 20.00
008 021901 SWITCH, RUN, FOR B3, C3 (LEVER) 49.90
008 016944 SWITCH, START,MOMENTARY ON, B3, C3 (LEVER) 25.90
AO 18728 KIT TONE GENERATOR CAP REBUILD KIT, A100/B3/C3 65.00
499 021468 TRIM CAP 20- 90 pF, OVERALL VOLUME TRIM 1.00
AO 18729 KIT VIBRATO LINE BOX CAP KIT A100,B3/C3 22.50

Leslie Parts


Part Number Description Amount
589 026708 #10 24 X 1 3/4 0.15
589 026625 #10 X 1 1/4"DIA FENDER WASHER 0.49
589 012849 #10-24 X 1 1/4 0.25
589 016832.0 #6 32 X 1 1/8", WITH SP-WASHER 1.25
589 026674 #6 32 X 2 1/2 0.30
589 025981 #6 WASHER SLOW MOTOR MOUNT 1.00
589 012930 #6-32 5/16 X 7/64 ZINC 1.00
589 025478 #8 32 X 1 0.15
589 026641 #8 X 1" DIA FLAT WASHER 1.00
589 026294 #8 X 32 X 1/4" ROUND HEAD 0.15
580 055186 HQ 100K OHM, 2 WATT, AUDIO TAPER. 19.00
504 059434 AC SOCKET FOR LESLIE AMP CHASSIS 3.75
511 035659 ADAPTER, LESLIE 5 TO 6 PIN 165.00
126 050039 AMPLIFIER, 147, OLD STYLE 499.00
589 029066 BACK SCREW & WASHER PHILLIPS 1.00
589 029066.KIT BACK SCREW SET, 13EA, BLK PHILIPS W WASHER 10.95
548 038067 BACK, MIDDLE 122 30.00
517 051045 BEARING, LOWER ROTOR 13.80
517 050716 BEARING, UPPER IDLER, W/O PULLY 10.00
522 011700 BELT, LOWER DRIVE, LARGE WHITE, ID 31" 18.25
522 045468 BELT, UPPER DRIVE,GREY,NEW STYLE 25.5" (WAS GREEN) 50.00
535 055053 BRACKET, AMP CHASSIS, FRONT, FLAT 10.00
535 055087 BRACKET, AMP CHASSIS, REAR HOLDDOWN 15.00
535 010728.N BRACKET, LOWER MOTOR ASSY MOUNTING 35.00
535 014266 BRACKET, LOWER MOTOR, MIDDLE MOUNTING 16.50
535 014068.N BRACKET, UPPER & LOWER SMALL MOTOR MOUNTING 14.95
535 017012 BRACKET, UPPER MOTOR, MIDDLE MOUNTING 16.78
517 055079 BUSHING, AMPLIFIER MOUNT 1.26
517 048991.1 BUSHING, LOWER MOTOR MOUNT 1.75
517 014050 BUSHING, SLOW MOTOR MOUNT- use with flat washer 0.60
517 050740 BUSHING, UPPER TENSION SPRING MT 0.75
511 029785 CABLE ASSY, 117V, 29" LONG, BROWN 3.63
511 029918 CABLE ASSY, 117V, 29" LONG, WHITE 1.60
511 029991 CABLE ASSY, 117V, 9" LONG, WHITE 1.60
511 029983 CABLE ASSY, 117V, 9"OR 29" LONG, BROWN 1.60
511 137330 CABLE, 11 COND BULK / FT. 3.38
511 137357 030 CABLE, 11 PIN 30 FT. 192.00
511 035659 030 CABLE, 5 PIN TO 6 PIN, 30 FT 147.00
511 010298 CABLE, 6 COND, BULK / FT. 4.85
511 017277 030 CABLE, 6 PIN, 30 FT 145.00
511 021618 CABLE, 9 COND, BULK / FT. 3.55
511 021600 030 CABLE, 9 PIN, 30 FT 142.00
578 033399 CAPACITOR, .0056 @ 1600V OR .0047 @ 2000V EA 2.25
578 027318 CAPICATOR, .1 @ 600V, RELAY CONTACT 2.52
578 029892 CAPICATOR, CAN 30/30/30/10 X 475 VOLT 54.16
014 020305 DIAPHRAGM FOR JENSEN HF DRIVER 65.00
543 122 KIT GROMMET KIT, 122 ALL RUBBER PARTS 46.70
543 050211 GROMMET, HORN DRIVER TO SPINDLE 1.50
543 051037 GROMMET, LOWER ROTOR BEARING & UPPER TENSION IDLER 1.00
543 051326 GROMMET, LOWER ROTOR MOUNT 5.00
543 050641 GROMMET, MOTOR BRAKET MOUNT-UPPER & LOWER 1.00
543 014084 GROMMET, SMALL, SLOW MOTOR MOUNT 1.00
517 026518 HARDWARE KIT, AMPLIFIER MOUNT 4 PIECE SET 1.00
514 140436 HORN, TREBLE, W/REFLECTORS 47.36
514 059468-A LESLIE DRIVER W/MTG, 100W, W/FERRO-FLUID 208.34
521 037564 MOTOR ASSY, LOWER 2 SPEED, W/O SHIELD, 60HZ 325.00
MK1D MOTOR SPEED CONTROLLER, F/S, ELECTRONIC 283.50
521 014795 MOTOR, LOWER SLOW (SHAFT DOWN) 84.88
521 014795.KIT MOTOR, LOWER SLOW, OLD STYLE REBUILD KIT 5.60
521 014019WT MOTOR, U&L FAST, W TRADE IN, REMANUFACTURED, 60HZ 85.00
521 054007 MOTOR, UPPER 2 SPEED ASSY 60HZ 300.00
521 012526 MOTOR, UPPER SLOW (NEW & OLD) 84.88
521 012526.KIT MOTOR, UPPER SLOW, OLD STYLE REBUILD KIT 5.60
543 014159 O RING, SLOW SPEED RIM DRIVE 7.75
541 013029 OIL SLINGER 1.88
505 137457.00 PLUG COVER KIT, LESLIE CABLE CONNECTORS 19.00
505 137457.01 PLUG COVER LESLIE CABLES, METAL W SCREW CLAMP 12.75
505 028845 PLUG, 11 PIN 20.00
505 013060 PLUG, 5 PIN MALE 28.00
505 061721 PLUG, 6 PIN MALE 18.00
505 061879 PLUG, 9 PIN 11.60
563 034496 POWER RELAY KIT FOR 122/147 193.71
522 126900 PULLEY, LOWER DRIVE, MODEL 820 25.00
522 050724 PULLEY, UPPER TENSION PULLEY ONLY, NO BEARING 15.00
522 018309 PULLY, LOWER 60hZ 26.00
503 055129 RELAY, 110VDC, 5K, SPDT (122) 87.45
503 027649 RELAY, 115 VAC, SPDT (147) 34.46
553 060954 ROTOR 15" DIA. COVER MODEL 25 24.95
553 018713 ROTOR 17" DIA. COVER (122, 147) 39.00
543 010751 RUBBER BUMPER, LOWER MOTOR BRACKET 1.00
504 028852 SOCKET, 11 PIN 11.00
504 029264 SOCKET, 5 PIN FEMALE 28.00
504 029546 SOCKET, 6 PIN FEMALE 25.75
504 020321 SOCKET, 8 PIN TUBE 5.88
504 028837 SOCKET, 9 PIN FEMALE 44.00
504 020339 SOCKET, 9 PIN TUBE 11.00
514 052308 SPEAKER, 15" 16 OHM BASS STOCK 152.00
508 015594RI SPEED SWITCH HOUSING W SW, REISSUE 112.50
514 052308.1 SPK, 15" 16OHM, 150W, 2"VC, 80 OZ MAGNET 127.05
512 050732 SPRING, TENSION UPPER BELT 13.45
517 051060 STANDOFF, LOWER ROTOR BEARING MOUNT 1.88
517 050294.2 STANDOFF, JBL STYLE DRIVER TO SPINDAL MT 1.18
517 050294 STANDOFF, OLD STYLE DRIVER TO SPINDAL MT 1.00
508 015594-A SWITCH ASSEMBLY, NEW STYLE SPEED SW 127.81
508 042911.2 SWITCH, SPEED, TOGGEL, METAL BAT HANDLE 14.95
508 042911.1 SWITCH, SPEED, TOGGLE, BLACK HANDLE 12.75
UC-1A UNIVERSAL COMBO PREAMP 660.00
543 050757 UPPER TENSION IDELER PAD 2.50
522 050708 UPPER TENSION IDLER ASSY 46.00
522 050716 UPPER TENSION PULLY AND BEARING 26.00
589 026328 WASHER, #10 LOWER BELT TENSION ADJUST 1.59
543 050260 WASHER, HORN MOUNT RUBBER WASHER 4.00
589 016832.1 WASHER, OLD SPINDEL MOUNT 1.04
999 050252 WASHER, TREBLE HORN SPINDLE THRUST 5.40
589 050625 WING NUT #10 X 24 1.00
589 050625.1 WING NUTS, CAN USE FOR 589 050625 0.25

Rhodes Parts


Part Number Description Amount
020022 SPRING, TB MTG, BLUE, #65-88, REAR, NOS 3.00
020014 SPRING, TB MTG, NATUAL, #26-61, #61-81 FRONT, NOS 3.00
069666 SPRING, TUNING, BLUE, 6 COIL, #41-88 3.00
011556 SPRING, TUNING, RED, 10 COIL HD, #0 ONLY 3.00
069658 SPRING, TUNING, YELLOW, 8 COIL, #23-40 3.00
008290 SUSTAIN BAR PIVOT PLATE 3.00
012925 SUSTAIN DAMPER PUSH ROD ASSY-LONG, SUITCASE 12.00
027647 SUSTAIN DAMPER PUSH ROD ASSY-SHORT, STAGE 12.00
027613 SUSTAIN PEDAL, STAGE PIANO, NEW 165.00
012822 SUSTAIN PEDAL, SUITCASE PIANO 71.00
027530 SUSTAIN ROD ASSY, STAGE PIANO, NEW 39.00
015287 SUSTAIN ROD ASSY, SUITCASE BOTTOM 49.00
013588 SWITCH, ROCKER, JANIS BOTTOM, NEW 19.95
012931 THUMBSCREW, SUSTAIN ROD, STAGE PIANO 1/4-20 X 1/2" 3.00
014651 THUMBSCREW, SUSTAIN ROD, STAGE PIANO 5/16 X 32 5.00
020097.NOS TINE, TONE GENERATOR 4", # 17 - 81 NOS 50.00
020063 TINE, TONE GENERATOR 6 1/2", #1 - 16 35.00
005 1343 000 TOLEX, 54" WIDE, SOLD BY YD 21.90
010457 TONE BAR - SPECIFY TONE BAR NUMBER $15.00 EA 15.00
012079 TONE BAR CLIP 3.00
037101 TRANSISTOR, 2N3391A 4.23
037119 TRANSISTOR, 2N3392 1.65

Moog Parts


Part Number Description Amount
910 042127 POLYMOOG SUSTAIN PLUG SMALL DIA 15.00
994 045072 001 TAURUS II INTERCONNECT CABLE 12FT 75.00

ARP Parts


Part Number Description Amount
2202601 CONTACT, L SERIES 3.00
2201701 CONTACT, STRAIGHT WIRE 1.00
4035 FILTER MODULE - ARP ODDYSSEY 129.00
2400103 FOOT, .675 ROUND, SCREW ON #6 2.34
916 043237 002 KEY GROMMET, 2.70
2401001 KNOB - ARP 2600 SLIDER 12.38
2400701 KNOB, PITCH BEND KNOB AXXE 8.00
2400401 SW CAP BLACK, ODYSSEY WHITE FACE 1.00
2400405 SW CAP BLUE, ODYSSEY WHITE FACE 1.00
2400404 SW CAP GREEN, ODYSSEY WHITS FACE 1.00
2400402 SW CAP RED, ODYSSEY WHITE FACE 1.00
2400408 SW CAP WHITE, ODYSSEY WHITE FACE 1.00
2400403 SW CAP YELLOW, ODYSSEY WHITE FACE 1.00

Wurlitzer Parts


Part Number Description Amount
201814 3K W/ON-OFF SW FOR 200 WURLETZER 25.00
200A PC ARP & WURLITZER, AC POWER JACK, OVAL 10.00
202266 CABLE ADAPTOR, SUSTAIN PEDAL 15.00
202265 CABLE, SUSTAIN PEDAL W/O ADAPTOR 65.00
201807 POWER TRANSFORMER 200 45.50
201890 REED SCREW 3.00
202253 SUSTAIN PEDAL ASSY MODEL 200 265.00
507661 TRANSISTOR 10.00
507664 TRANSISTOR 10.00
